Trace the load.

Predict a load path. Change one input. Compare the calculated response.

Rivetcross pairs editable educational studies with a separate collection of 120 bridge puzzles. Paid once. No ads, account or in-app purchases.

Actual Rivetcross two-panel study, with signed member forces and support reactions

Define the model

Coordinates, independent X/Y support restraints, axial rigidity, entered limits and nodal loads. Start blank or explicitly choose an input example.

Compare the bracing

Keep geometry and loads common across up to three member layouts and eight cases. Inspect forces, displacements and support reactions. An unstable system has no invented result.

Test a prediction

Choose a side load or member-stiffness intervention. Predict its effect, then calculate both models. Inspect support reactions, member forces and displacement. Use the changed inputs in your own study.

Keep the inputs

Save 24 studies locally. Import or export editable JSON through Files, export every case as CSV, or export a selected case as a standalone SVG with measured tables.

Dimensionless model units. Ideal pin-jointed, linear, small-displacement trusses. No bending, buckling or construction approval. Entered limits are comparison inputs, not certified capacities.
